Connector Housing - 10-Position IDC - 0.100 Inch Spacing:

Price: $1.19 each
Status: In Stock
(7 Available)

Order:

Part #: A31060-10
Condition: New

Connector housing, 10-position, 0.100-inch spacing, IDC type (Insulation Displacement Connector).

IDC housings have built-in pins, and wires are pressed or staked into the back of the housing to secure.

These housings accommodate wires in the range of 16-22 AWG (ie: most all common pinball and video game applications).

Locking Ramp: IDC connector housings come with locking ramp tabs molded in, which will lock into place on corresponding pin units that have friction lock backing. Housings with locking ramp can also be installed with pin units that have no backing for locking ramps, and vice-versa.

Replaces Bally/Williams # 5792-12116-10.

NOTE: No returns on Electronics - all sales final.

Ask a question about this item

Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
BALLY: Addams Family, Addams Family Gold, Attack From Mars, Black Rose, Champion Pub, Cirqus Voltaire, Eight Ball Deluxe, Fathom, Flash Gordon, Indianapolis 500, Judge Dredd, Medusa, NBA Fastbreak, Scared Stiff, Theatre of Magic, Vector, WhoDunnit, World Cup Soccer '94, Xenon, more

WILLIAMS: Demolition Man, Dirty Harry, Flintstones, JackBot, Johnny Mnemonic, Junk Yard, No Fear, No Good Gofers, Star Trek: The Next Generation, Tales of the Arabian Nights
