Pompeii shuffle (Williams) Game Manual and Schematics (Reprint):

Price: $35.50 each
Status: In Stock

Order:

Part #: PM0310
Condition: New (Reprint)

52 pages. Includes game setup/operating info and fold-out electronic schematics & wiring diagrams. Reprint manual in new condition.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
WILLIAMS: Pompeii (shuffle)
