Simpsons (Data East) Game Manual and Schematics (Reprint):

Price: $33.32 each
Status: In Stock

Order:

Part #: PM0337
Condition: New (Reprint)

63 pages. Includes info on game setup, operation, adjustments, settings, bookkeeping/audits, diagnostics, parts diagrams & listings, and fold-out electronic schematics & wiring diagrams. Reprint manual in new condition. Original factory part # 780-5012-00.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item
