WPC Schematic Manual - Large (Bally/Williams) (ORIGINAL):

Price: $22.50 each
Status: Out of Stock
Part #: PM0447
Condition: Used (Original)

For use with Bally and Williams "WPC-89" games made from approx. 1990-1994. Approx. 15 pages. This is the manual that specifically covers the circuit boards, display unit, and power/transformer cabinet wiring in these games. Your actual game instruction/operation manual covers only the game-specific (playfield) circuit boards and wiring, but this manual covers the rest! Essential for any circuit board troubleshooting/repair, electronic component ID, and a must to complete any WPC-89 game.

Factory-original manual in used/good condition. Measures 11 x 17 inches.

NOTE: No returns on Paperwork Items - all sales final.

NOTE: No warranty or returns on used items. Used items are sold as-is, and all sales are final.

Ask a question about this item

Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
BALLY: Addams Family, Addams Family Gold, Black Rose, Corvette, Creature From the Black Lagoon, Doctor Who, Gilligan's Island, Harley Davidson, Indianapolis 500, Judge Dredd, Party Zone, Popeye, Shadow, Theatre of Magic, Twilight Zone, World Cup Soccer '94

WILLIAMS: Demolition Man, Dracula, Fish Tales, Funhouse, Getaway, Hurricane, Indiana Jones, Machine: Bride of PinBot, No Fear, Road Show, Star Trek: The Next Generation, Terminator 2, White Water
