Bally Repair Procedures Manual FO-560 (June 1977) (USED) (SEE NOTES):
Price: $20.00 each
Status: In Stock
(1 Available)
Part #: PM0454
Condition: Used - Good
|
|
|
Used original manual in good condition. Image is sample only- condition of actual manual may vary.
Electronic Pinball Games Repair Procedures #FO-560 (June, 1977). 64 pages. For use with electronic solid-state (SS) Bally pinball games made between 1977 - mid 1978 (6800 processor-based games w/ MPU board -17, -35). See Sound Board Notes, and game listing, below.
This manual covers electronic circuit board and score display diagnostics, some basic high-level board repair procedures, and board replacement.
It includes about 3 times more info than what is found in your individual game manual. MPU self-test procedures, basic troubleshooting flow charts, and board diagrams/part listings (as found in individual game manual) are included in this manual, with the addition of many more in-depth symptom/cause diagnostic/repair procedures for each of the circuit boards and score displays.
NOTES:
Some of the procedures in this manual involve the use of the Bally "AID" or "AID1" module. AID was a small factory-produced add-on circuit board (module) that plugged in to connector J5 at the top of the MPU board. The AID modules are no longer produced, so some of the info in this manual involving their use may not be of use to you.
SOUND BOARD NOTES:
This manual does not include any information on early sound boards (applies only to games with scoring chimes). If you need a manual with sound board info, please see manual # FO-560-3 instead.
Used manual in good condition. Some minor handwriting and signs of age/use may be present.
NOTE: No returns on Paperwork Items - all sales final.
NOTE: No warranty or returns on used items. Used items are sold as-is, and all sales are final.
Ask a question about this item
Used In The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
BALLY: Black Jack, Eight Ball, Evel Knievel, Mata Hari, Night Rider, Strikes and Spares, more
|
