Wizard! (Bally) Game Manual and Schematic Wiring Diagrams Set - 3pcs (Reprint) (SEE NOTE):
Price: $56.00 set
Status: In Stock
Part #: PM0486
Condition: New (Reprint)
|
|
|
Buy together and save! 3-piece set of game manual and fold-out schematic wiring diagrams for Bally Wizard! pinball, made in 1975.
Manual is 11 pages and includes info on game setup, operation, game features and scoring, game adjustments, and top-side playfield diagram with part listings and part numbers.
Wiring diagrams include VERY large fold-out main schematic diagram (see notes below), and separate coin chute circuits diagram. Features diagrams of all circuits with listings of relays/coils/solenoids and part numbers.
NOTES: - These are reprints of 50+ year-old original documents.
- Main schematic has some printing that is a bit light and hard to read in some areas due to age/condition of original.
- Diagrams ship folded.
- Unfolded, main schematic measures approx. 10 feet long by 2 feet wide.
NOTE: No returns on Paperwork Items - all sales final.
