Gilligans Island (Bally) Game Manual (No Schematics) (Reprint):

Price: $46.50 each
Status: In Stock

Order:

Part #: PM0626
Condition: New (Reprint)

114 pages. Includes game operating/adjustment instructions, parts listing, adjustments/settings, game-specific wiring diagrams.

Does not include backbox PCB circuit board and display schematics section (order manual # PM0447 if you need PCB schematics).

Reprint manual in new condition. Original factory part # 16-20003-101.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
BALLY: Gilligan's Island
