Williams Pinball Troubleshooting and Reference Manual - 1986 (Reprint):

Price: $38.50 each
Status: In Stock

Order:

Part #: PM0640
Condition: New (Reprint)

79 pages. Shop diagnostic and troubleshooting / repair manual for Williams electronic solid-state (SS) pinball games. Dated April 21, 1986. Can be used with Williams System 9 and System 11 games from this era, all the way back to the first electronic models in 1977 (Level 3 through Level 7 games). Includes a wealth of information on how to service and repair mechanical parts, low-level circuit board components, switch and lamp matrix, solenoids, flippers, bumpers, displays, and more. Includes lots of diagrams, illustrations, schematics, theory of operation, and adjustment information.

A must if you want to know what makes your Williams pinball tick and how to go about doing your own diagnosing and repair work.

Reprint manual in new condition.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
WILLIAMS: Alley Cats (shuffle), Comet, Grand Lizard, High Speed, Road Kings, Sorcerer, Space Shuttle, Star Light, Strike Zone, more
