Motordome (Bally) Game Manual Set (2pcs) (Reprint):

Price: $59.25 each
Status: In Stock

Order:

Part #: PM0862
Condition: New (Reprint)

Buy together and save! Set of 2 manuals for Bally Motordome pinball: Operation Manual and Parts Manual.

Operation Manual is 46 pages and includes info on game setup, operation, adjustments, troubleshooting, parts listings and diagrams, and fold-out electronic schematics and wiring diagrams.

Parts Manual is 52 pages and includes full parts listings with part numbers and diagrams.

Reprint manuals in new condition. Original factory part #s 0E14-00300-0100 and 0E14-00300-0200, respectively.

NOTE: No returns on Paperwork Items - all sales final.

Ask a question about this item

Fits The Following Games: (The list below may not be complete, and it's accuracy is not guaranteed. Contact us if you have any questions.)
BALLY: Motordome
